Processor module：
| Jetson Orin Nano 4GB | Jetson Orin Nano 8GB | |
|
AI Performance |
20 TOPS | 40 TOPS |
| GPU |
512-core NVIDIA Ampere 16 Tensor architecture GPU with Cores |
1024-core NVIDIA Ampere 32 Tensor architecture GPU with Cores |
| CPU |
6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 |
|
|
Video Encode |
1080p30 supported by 1-2 CPU
cores |
|
|
Video Decode |
1x 4K60 (H.265)
(H.265) 5x 1080p60 (H.265) 11x 1080p30 (H.265) |
|
| Memory |
4GB 64-bit LPDDR5 34 GB/s |
8GB 128-bit LPDDR5 68 GB/s |
| Storage | —
(Supports external NVMe) |
|
|
Jetson Orin NX 8GB |
Jetson Orin NX 16GB | |
| AI Performance | 70 TOPS | 100 TOPS |
| GPU |
1024-core NVIDIA Ampere GPU with 32 Tensor Cores |
|
| CPU |
6-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 |
8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 2MB L2 +4MB L3 |
| Video Encode |
1x 4K60 | 3x 4K30 | 6x 1080p60 | 12x 1080p30 (H.265) 1x 4K60 | 2x 4K30 | 5x 1080p60 | 11x 1080p30 (H.264) |
|
| Video Decode |
1x 8K30 | 2x 4K60 | 4x 4K30 | 9x 1080p60| 18x 1080p30 (H.265) 1x 4K60 | 2x 4K30 | 5x 1080p60 | 11x 1080p30 (H.264) |
|
| Memory |
8 GB 128-bit LPDDR5 102.4 GB/s |
16 GB 128-bit
LPDDR5 102.4 GB/s |
| Storage |
— (Supports external Storage NVMe) |
|
Product specification：
| Interface | Specification |
| Network | 1 × Gigabit Ethernet Connector (10/100/1000) |
| USB |
2x USB 3.0 Type A (Integrated USB 2.0) 1x USB 3.0 0.5mm pitch 20P ZIF 1x USB 2.0 Micro-AB |
| Video output |
1 × HDMI |
| SIM Card | 1x SIM Card |
| CAN |
1 × CAN |
| RS232 |
1x RS232 |
| Function Key | 1x Reset key ;1x Recovery key |
| Project | Specification |
| Input Voltage | +9V to +20V DC Input @ 7A |
| Load capacity | Above 60W |
|
Dimensions (W×D ×H) |
94x92x51 (mm) |
|
Operating Temperature |
-25℃-65℃ 0.2~0.3m/airflows |
|
Storage Temperature |
-20℃-60℃ |
| Weight | 0.390KG |
Schematic diagram of dimensions：
| Front view | Left view |
 |
 |
| Up view | Right view |
 |
 |
